What else
do you need?

POSEIDON

AWARD-WINNING PRODUCT

SGIA, Product of the year, 2019
RTR Dye-Sub on Textile

In 2024,

POSEIDON II

launched

The heritage of

POSEIDON

X4
SPEED

INDUSTRIAL LEVEL
DYE SUBLIMATION PRINTER

Up to

760㎡/h

SPEED


Up to

600 X 1,800dpi

RESOLUTION

This data is based on the specifications of
the 8-head (2-stagger) model.

The 4-head and 8-head (8-colour) models are
also available as bespoke options.

KEY FEATURES

HEAD COOLING SYSTEM

The water based head cooling system maintains the temperature of the print head to enable continuous printing and improve runability.

THE S-SHAPED SUCTION PLATE

The new suction system has been implemented to minimize cockling issues that may occur when using a large amount of ink on low-weight transfer paper.

NEWLY DESIGNED WIPING SYSTEM

The chain wiping and automatic water flushing system maintain optimal blade conditions, thereby eliminating the need for operators to clean the printhead blades.

LINEAR MOTOR AND
METAL ENCODER SCALE

The linear motor and metal encoder scale ensure high-precision printing, while also maintaining low operational and maintenance costs.

JUMBO ROLL
UNWINDING SYSTEM

The jumbo roll unwinding system has a loading capacity that can support a maximum paper diameter of 800mm and a maximum weight of 700kg . (*Optional)

BULK TYPE INK REFILL SYSTEM (10L)

The bulk type Ink system, which is very simple and accessible, is designed for ink refilling, even during printing, to enable mass printing.

SPECIFICATIONS

Printing


Print Head
Kyocera, 4/8 Heads

Ink Type
Water Based Dye Sublimation

Water Based Graphic Pigment

Number of Colour
4 / 8

Max Printing Resolution
600 X 1,800dpi

Max Printing Width
1,820mm

Printing Mode
Bi-Direction/Uni-Direction

Ink



Water Based Dye Sublimation (4 Colour)

Yellow, Magenta, Cyan, Black


Water Based Dye Sublimation (8 Colour)

Yellow, Magenta, Cyan, Black Lc, Lm, Fm, Fy


Water Based Graphic Pigment (4 Colour)

Yellow, Magenta, Cyan, Black

Ink Capacity
10L

Printing Speed


300 X 600dpi 1pass
760㎡/h

600 X 600dpi 1pass

500㎡/h


300 X 1,200dpi 2pass

350㎡/h


508 X 1,200dpi 2pass

280㎡/h


600 X 1,800dpi 3pass
155㎡/h

Getting
in Touch

We look forward to responding to your
questions. We will contact you with a expert
within the next 24 hours.

What else do you need?

POSEIDON

AWARD-WINNING PRODUCT

SGIA, Product of the year, 2019
RTR Dye-Sub on Textile

In 2024,

POSEIDON II

launched

The heritage of

POSEIDON



X4 SPEED

INDUSTRIAL LEVEL DYE SUBLIMATION PRINTER

Up to


760㎡/h

Speed

Up to


600
X 1,800
dpi

Resolution

This data is based on the specifications of the 8-head (2-stagger) model.
The 4-head and 8-head (8-colour) models are also available as bespoke options.

KEY FEATURES

HEAD COOLING SYSTEM

The water based head cooling system maintains the temperature of the print head to enable continuous printing and improve runability.

LINEAR MOTOR AND METAL ENCODER SCALE

The linear motor and metal encoder scale ensure high-precision printing, while also maintaining low operational and maintenance costs.

THE INVENTIVE S-SHAPED SUCTION PLATE

The new suction system has been implemented to minimize cockling issues that may occur when using
a large amount of ink on low-weight transfer paper.

NEWLY DESIGNED WIPING SYSTEM

The chain wiping and automatic water flushing system maintain optimal blade conditions, thereby eliminating the need for operators to clean the printhead blades.

JUMBO ROLL UNWINDING SYSTEM

The jumbo roll unwinding system has a loading capacity that can support a maximum paper diameter of 800mm and a maximum weight of 700kg. (*Optional)

BULK TYPE INK REFILL SYSTEM (10L)

The bulk type Ink system, which is very simple and accessible, is designed for ink refilling, even during printing, to enable mass printing.

SPECIFICATIONS

Printing


Print Head
Kyocera, 4/8 Heads

Ink Type
Water Based Dye Sublimation
Water Based Graphic Pigment

Number of Colour
4 / 8

Max Printing Resolution
600 X 1,800dpi

Max Printing Width
1,820mm

Printing Mode
Bi-Direction/Uni-Direction

Ink


Water Based Dye Sublimation (4 Colour)
Yellow, Magenta, Cyan, Black

Water Based Dye Sublimation (8 Colour)
Yellow, Magenta, Cyan, Black
Lc, Lm, Fm, Fy


Water Based Graphic Pigment (4 Colour)
Yellow, Magenta, Cyan, Black


Ink Capacity
10L

Printing Speed


300 X 600dpi 1pass

760㎡/h


600 X 600dpi 1pass

500㎡/h


300 X 1,200dpi 2pass

350㎡/h


508 X 1,200dpi 2pass

280㎡/h


600 X 1,800dpi 3pass

155㎡/h




Getting
in Touch

We look forward to responding to your questions.
We will contact you with a booster expert within
the next 24 hours.
