REGULAR
TOO EASY,

PROFESSIONAL
TOO HARD?

All New Designed

FABRIC FEEDING SYSTEM
STICKY BELT FEEDING SYSTEM

EASY TO PRINT ELASTIC FABRICS WITH THE HIGHEST PRECISION

POWERFUL DRYER SUITABLE FOR WIDE VARIETIES OF FABRICS

FULLY AUTOMATED TENSIONING AND ALIGNING DEVICES

ARTRIX PRO

AN EASY WAY TO BE A PROFESSIONAL

INDUSTRIAL LEVEL
DIRECT TO TEXTILE PRINTER


Up to

129㎡/h

SPEED


Up to

600 X 1,800dpi

RESOLUTION

KEY FEATURES

RICHO GEN 6

Compared to the current models of Ricoh G5 available on the market, it offers a 30% increase in speed, significantly improving printer efficiency.

LINEAR MOTOR AND
METAL ENCODER SCALE

The linear motor and metal encoder scale ensure high-precision printing, while also maintaining low operational and maintenance costs.

POWERFUL IN-LINE DRYER

The In-line dryer is equipped with six infrared lamps, making it more powerful and explicitly designed to efficiently dry even the thickest fabrics at high speeds.

HIGHLY VERSATILE
FABRIC FEEDING SYSTEM

The feeding system provides edge positioning control to ensure perfect feeding. Additionally, it incorporates a pneumatic clutch to prevent distortion of the media.

ADVANCE BELT WASHING UNIT

Equipped with a powerful brush and dryer, the advanced belt washing unit enhances the long- lasting tackiness of the glue.

SMART FABRIC PRESS ROLLER

The smart fabric press roller finely regulates pressure in order to ensure stable printing and prevent distortion of the media.

SPECIFICATIONS

Printing


Print Head
Ricoh, 8 Heads

Ink Type
Pigment

Number of Colour
8

Max Printing Resolution
600 X 1,800dpi

Max Printing Width
1,830mm

Printing Mode
Bi-Direction/Uni-Direction

Ink



Pigment
Yellow, Magenta, Cyan, Black,
+ Lc, Lm, Or, Bl, Sc, Gr

Ink Capacity
5L

Printing Speed


600 X 600dpi 2pass
129㎡/h

600 X 900dpi 3pass
93㎡/h

600 X 1,200dpi 4pass
72㎡/h

Getting
in Touch

We look forward to responding to your
questions. We will contact you with a expert
within the next 24 hours.

REGULAR
TOO EASY,

PROFESSIONAL

TOO HARD?

All New Designed

FABRIC FEEDING SYSTEM
STICKY BELT FEEDING SYSTEM

EASY TO PRINT ELASTIC FABRICS WITH THE HIGHEST PRECISION

POWERFUL DRYER SUITABLE FOR WIDE VARIETIES OF FABRICS

FULLY AUTOMATED TENSIONING AND ALIGNING DEVICES

ARTRIX PRO

AN EASY WAY TO BE A PROFESSIONAL

INDUSTRIAL LEVEL DIRECT TO TEXTILE PRINTER

Up to


129㎡/h

Speed

Up to


600
X 1,800
dpi

Resolution

KEY FEATURES

RICHO GEN 6

Compared to the current models of Ricoh G5 available on the market, it offers a 30% increase in speed, significantly improving printer efficiency.

LINEAR MOTOR AND METAL ENCODER SCALE

The linear motor and metal encoder scale ensure high-precision printing, while also maintaining low operational and maintenance costs.

POWERFUL IN-LINE DRYER

The In-line dryer is equipped with six infrared lamps, making it more powerful and explicitly designed to efficiently dry even the thickest fabrics at high speeds.

HIGHLY VERSATILE FABRIC FEEDING SYSTEM

The feeding system provides edge positioning control to ensure perfect feeding. Additionally, it incorporates a pneumatic clutch to prevent distortion of the media.

ADVANCED BELT WASHING UNIT

Equipped with a powerful brush and dryer, the advanced belt washing unit enhances the long- lasting tackiness of the glue.

SMART FABRIC PRESS ROLLER

The smart fabric press roller finely regulates
pressure in order to ensure stable printing and
prevent distortion of the media.

SPECIFICATIONS

Printing


Print Head
Ricoh, 8 Heads


Ink Type
Pigment

Number of Colour
8

Max Printing Resolution
600 X 1,800dpi

Max Printing Width
1,830mm

Printing Mode
Bi-Direction/Uni-Direction

Ink


Pigment
Yellow, Magenta, Cyan, Black,
+ Lc, Lm, Or, Bl, Sc, Gr

Ink Capacity
5L

Printing Speed


600 X 600dpi 2pass

129㎡/h

600 X 900dpi 3pass
93㎡/h

600 X 1,200dpi 4pass
72㎡/h




Getting
in Touch

We look forward to responding to your questions.
We will contact you with a booster expert within the next 24 hours.
